The DLKZS Reversible Hammer Sand Making Machine features a single rotor capable of forward and reverse rotation. By combining the advantages of reversible hammer crushers and double-rotor sand makers, it delivers stable performance, easy maintenance, and intelligent operation. The machine is suitable for both sand making and aggregate production, including crushing hard rock materials.
Applications: Sand making, aggregate production, hard rock crushing
Suitable Materials: Limestone, bluestone, granite, pebbles
Capacity: 100–250 T/H
Max Feed Size: ＜180 mm
| model |
Rotor diameter * length （mm） |
Feed particle size （mm） |
power （kw） |
production capacity （t/h） |
|---|---|---|---|---|
| DLKZS1314 | 1340x1430 | ＜180 | 200x2 | 100~200 |
| DLKZS1616 | 1600x1630 | ＜180 | 250x2 | 150~250 |
The end inspection door features a hydraulic opening mechanism for flexible operation; the large size of the inspection opening facilitates maintenance of the rotor and other components by maintenance personnel.
A high-efficiency sand and aggregate crusher with a reversible rotor, designed for stable operation, easy maintenance, and reliable crushing of medium to hard materials.
Conact Us
A reversible hammer sand making machine is a single-rotor crusher with a rotor that can rotate in both directions. This design allows both sides of the hammer heads to be used without manual flipping, ensuring even wear and longer service life.
The DLKZS series is suitable for medium-to-low hardness materials such as limestone and bluestone, as well as hard rock materials like granite and river pebbles, making it versatile for sand and aggregate production.
The reversible rotor eliminates the need to flip hammer heads manually. By changing the rotation direction, wear on hammers, liners, and grate plates is evenly distributed, reducing downtime and maintenance costs.
Yes. The machine features hydraulic opening inspection doors, adjustable grate gaps, and a simplified hammer shaft removal design, allowing fast replacement of wear parts and easy routine maintenance.
The DLKZS reversible hammer sand making machine provides a processing capacity of 100–250 tons per hour, with a maximum feed size of ≤180 mm, suitable for medium and large-scale sand production lines.
Yes. Please feel free to contact us.
